Product Details:
Payment & Shipping Terms:
|
| Gross Weight:: | 45KG | Material:: | PVC Panel With Fireproof Material |
|---|---|---|---|
| Standard External Size: | 2203mm(H)*860mm(W)*480mm(D) | Standard Internal Size: | 1980mm(H)*700mm(W)*400mm(D) |
| Packaging Size For Door Panels: | 2260*550*235mm*1ctn | Packaging Size For Control Unit: | 750*340*240mm*1ctn |
| Zones:: | 2260*650*260m6 Zones Basicm *1ctn | Alarm:: | Sound & LED Alarm |
| Sensitivity:: | 100 Sensitivity Level | Warranty:: | 2 Years |
| Highlight: | metal detector security gate,walk through metal detector rental |
||
Economic 6 zones UB500 door frame metal detector manufactured by UNIQSCAN used in hotel, school
Hot sales 6 zones DFMD with 4 digital LED counter, high sensitivity, competitive price, 2 years warranty
WALK THROUGH METAL DETECTOR
MODEL:UB500 Economic/6 zones standard
Parameters:
| Power Supply: | AC85V-264V |
| Working temperature: | -20℃--+50℃ |
| Working Frequency : | 4KHZ—8KHZ |
| Standard External size: | 2203mm(H)*860mm(W)*480mm(D) |
| Standard Internal size: | 1980mm(H)*700mm(W)*400mm(D) |
| Package size for door panels: | 2260*550*235mm*1ctn |
| Package size for control unit: | 750*340*240mm*1ctn |
| Gross weight: | 45KG |
Characteristic & Function & selling points
Ø Six mutual over-lapping detecting zones, Simultaneous alarm from multi- zones;
Ø Sensitivity adjustable: Each zone has 100 sensitivity level
Ø Sound & LED alarm: easily show where the metal is.
Ø Automatically count passengers and alarm times
Ø Alarm strength indicator on control panel
Ø Password protection: only the authorized person can operate.
Ø Easy assembly: designed with only 2 pieces cables and 8 screws, simply-to-follow instruction.
Ø Harmless to human body:is harmless with heart pacemaker, pregnant women, magnetic floppy, recording tapes, etc.
Ø Using high density fireproof material
Ø Program Self-diagnostic when power on, no need initial or periodic calibration
Ø Modularization design:easy for maintenance and replacement.
Ø Sensitivity Test piece: One yuan Coin, omnidirectional detection
Ø LED indication: 6 LED strips on the top of the reference level showing the trigger zone
Ø 4-8 hours backup battery (Option)
