Product Details:
Payment & Shipping Terms:
|
| Power Supply:: | AC85V-264V | Working Temperature:: | -20℃--+50℃ |
|---|---|---|---|
| Working Frequency:: | 4KHZ-8KHZ | Standard External Size:: | 2230mm(H)X830mm(W)X730mm(D) |
| Standard Internal Size:: | 2010mm(H)X700mm(W)X500mm(D) | Package Size For Door Panels:: | 2280*730*210mm *1ctn |
| Package Size For Control Unit:: | 780*380*260m*1ctn | Gross Weight:: | 63KG |
| Backup Battery: | 4-8 Hours | LCD Screen: | Small |
| High Light: | walk through x ray machine,walk through safety gate |
||
UB600 password protection with 18 zones adjusted sensitivity with LED alarm light cheap door frame metal detector
1,Company instruction
Shenzhen Unisec Technology Co., Ltd is a professional security scanner equipment manufacturer, specialized the development and research in the x-ray imagine tehnology, metal detection technology, explosive detection, liquid detection and relative security services.
OUR BRIEF
We always adhere to customer-centric, the principles of honesty and trustworthiness, is committed to efforts to improve and continuous innovate its own responsibility .
OUR TECHNOLOGY
We owns all of the intellectual property rights (IPR) to its core technologies ,and have a experience engineer team with senior x-ray detection exports, signal and imagine processing specialist , excellent technical support and maintance engineers.
OUR SERVICES
We strictly in accordance with the ISO9001 quality standard requirements from production research , manufacture, marketing to after services, established a complete quality management and assurance system . Also we take effective marketing management protection measures to control the products qulity ,working efficiency and service attitudes ,to ensure all our clients have our best quality products and best services.
2,Specification
6/12/18 Zone Walk Through Metal Detector UB600
Parameters
Power Supply: AC85V-264V
Working temperature: -20℃--+50℃
Working Frequency : 4KHZ—8KHZ
Standard External size: 2200mm(H)X800mm(W)X580mm(D)
Standard Internal size: 2010mm(H)X700mm(W)X500mm(D)
Package size for door panels: 2290*560*180mm *1ctn
Package size for control unit: 760*380*260 mm*1ctn
Gross weight: 63KG
Characteristic & Function
Ø 18 mutual over-lapping detecting zones, Simultaneous alarm from multi- zones;
Ø Small LCD screen, English operating software, easy to operate.
Ø Sensitivity adjustable: Each zone has 256 sensitivity level, 0-255 adjustable
Ø Sound & LED alarm: Both Side LED indicator ,
easily show where the metal is.
Ø Automatically count passengers and alarm times
Ø Alarm strength indicator on control panel
Ø Password protection, only the authorized person can operate.
Ø Easy assembly: designed with only 2 pieces cables and 8 screws, simply-to-follow instruction.
Ø Harmless to human body: is harmless with heart pacemaker, pregnant women, magnetic floppy, recording tapes, etc.
Ø Using high density fireproof material
Ø Program Self-diagnostic when power on,no need initial or periodic calibration
Ø Modularization design,easy for maintenance and replacement.
Ø Sensitivity Test piece: One yuan Coin, omnidirectional detection
Ø 4-8 hours backup battery (Option)
Use domain
Exhibition center, Electronic Factory, Bank, Prison, Government office,Hotel etc
3,Production process
4,Package
5,Successful cases
6,Exhibitions
7,Our service
8,FAQ
