UVSS / UVIS Fixed Under Vehicle Inspection System CCD Line Scan IP68 Protection Level

UVSS / UVIS Fixed Under Vehicle Inspection System CCD Line Scan IP68 Protection Level
UVSS / UVIS Fixed Under Vehicle Inspection System CCD Line Scan IP68 Protection Level

Large Image :  UVSS / UVIS Fixed Under Vehicle Inspection System CCD Line Scan IP68 Protection Level

Product Details:
Place of Origin: China
Brand Name: UNIQSCAN
Certification: CE ISO
Model Number: UV-300F
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: USD
Packaging Details: wooden box
Delivery Time: 5~7 days
Payment Terms: T/T, L/C
Supply Ability: 500 UNIT PER MONTH
Detailed Product Description
Product Name: Under Vehicle Inspection / Surveillance Light Systems (UVSS) Model: UV300-F
Protection Level: IP68 Warranty: Two Year Free
High Light:

under vehicle bomb detector

,

under car bomb detector



UVSS/UVIS fixed under vehicle inspection system CCD line scan



Parameters:

1. Store or load time: <1 second;

2. Vehicle Image local magnification: > 2 times;

3. Vehicle Image scaling: 16 times;

4. Vehicle image display mode: large format transverse;

5. Vehicle image storage format: BMP or JPEG;

6. System interface language: English (can be customized);

7. Display resolution: 1920 * 1080P

8. Communication interface: RS232/RS422;

9. Scene image display: ≥1 channel



UVSS / UVIS Fixed Under Vehicle Inspection System CCD Line Scan IP68 Protection Level 0

10. Speed identification: when the vehicle pass the scanner and stops suddenly, then restart, the device can identify automatically, system will display the complete vehicle image

11. Scan mode: linear scanning, the ground sensor coil trigger;

12. Vehicle speed: 1-60km/h, suggest speed : less than 30km/h

13. View angle: 175 degrees

14. Image Longitudinal resolution: 2048 pixels CCD;

15. Scanner connecting cable: 100 meters (can be customized)

16. Lighting components : Four single sealed LED surface light source ;

Life : 100,000h

17. Under Vehicle image scanner with a unique open-wide field scan design;

18. Working voltage: DC24V

19. Power Supply:AC110V-240V/50-60Hz

20. Structure design:single sealed design;

21. Loading weight: 30 Tons

22. Scanner size: 1200*350*210mm

23. Weight: 180kg

24. Environment temperature: -40 degrees - +70 degrees

25. License plate recognition

UVSS / UVIS Fixed Under Vehicle Inspection System CCD Line Scan IP68 Protection Level 1
