Upward Xray Luggage Scanner X Ray Parcel Scanner With 80° Angle

Upward Xray Luggage Scanner X Ray Parcel Scanner With 80° Angle
Upward Xray Luggage Scanner X Ray Parcel Scanner With 80° Angle

Large Image :  Upward Xray Luggage Scanner X Ray Parcel Scanner With 80° Angle

Product Details:
Place of Origin: China,Guangdong
Brand Name: UNIQSCAN
Certification: CE,ISO
Model Number: SF6040
Payment & Shipping Terms:
Minimum Order Quantity: 1unit
Price: $10500/unit
Packaging Details: External Dimension L*W*H (mm) 2080*864*1193 Package Dim. with wooden case L*W*H (mm) 2250*970*1350
Delivery Time: 5 days after got payment
Payment Terms: TT
Supply Ability: 200units/month
Detailed Product Description
Tunnel Size ::: 600(W) X400(H) Mm Single Inspection Dosage::: <1.01μGy
Steel Penetration::: 40mm System Power::: 220 VAC (±10%) 50±3HZ
Conveyor Speed::: 0.22m/s Leakage Radiation::: <0.06μGy/h
Film Safety::: For ISO 1600 Conveyor Max Load::: 150 Kg
Wire Resolution::: 40AWG Angle::: 80°
High Light:

x ray scanning machine

,

airport x ray machines

xray parcel scanner/xray baggage scanner/xray luggage scanner







Company information

ABOUT US

Shenzhen Unisec Technology Co., Ltd is a professional security scanner equipment manufacturer, specialized the development and research in the x-ray imagine tehnology, metal detection technology, explosive detection, liquid detection and relative security services.

OUR BRIEF

We always adhere to customer-centric, the principles of honesty and trustworthiness, is committed to efforts to improve and continuous innovate its own responsibility .

OUR TECHNOLOGY
We owns all of the intellectual property rights (IPR) to its core technologies ,and have a experience engineer team with senior x-ray detection exports, signal and imagine processing specialist , excellent technical support and maintance engineers.

OUR SERVICES
We strictly in accordance with the ISO9001 quality standard requirements from production research , manufacture, marketing to after services, established a complete quality management and assurance system . Also we take effective marketing management protection measures to control the products qulity ,working efficiency and service attitudes ,to ensure all our clients have our best quality products and best services.



Upward Xray Luggage Scanner X Ray Parcel Scanner With 80° Angle 0





General Specifications

Tunnel Size : 600(W) ×400(H) mm

Conveyor Speed: 0.22m/s

Conveyor Max Load: 150 kg

Single inspection dosage: <1.01μGy

Leakage radiation: <0.06µGy/h

Wire Resolution: 40AWG

Steel Penetration: 40mm

Film Safety: For ISO 1600



X-RAY GENERATOR

Orientation: Upward

Tube Current: 0.4-1.25mA(adjustable)

Anode Voltage: 80-160KV(adjustable)

Angle: 80°

Generator cooling/working periods:

Sealed oil bath with forced air/100%



OPERATING ENVIRONMENT

Storage Temperature: -20oC to 60oC

Operating Temperature: 0oC to 45oC

Relative Humidity:

20 to 95% non-condensing

System Power: 220 VAC (±10%) 50±3HZ

Power wastage: 1.0 KW (Max)

Noise<55DB

X-RAY Sensor: L-shaped array detector, 24bit

Image Performance System:

Display: High-resolution 19 inch color LCD display

Edge enhancement: Object contour edge is more distinct

Super image enhancement: Image detail is more distinct

High penetration display: Increase the contrast of bright area in image to make the area that is easy to penetrate appear more clearly

Low penetration display: Increase the contrast of dark area in image to make the area that is difficult to penetrate appear more clearly.

Magnifier: Partial magnifying function

Brightening/dimming: Increase/Decrease brightness of image

Image recurrence: Display the previous twenty images and process any one of them

Image restoration: Restore image to initial status

Image storage: Real-time store any image and process it in operation status



Multi-energy: High/low energy: Switch from high energy to low energy

Color material identification: Organic objects in orange, inorganic objects in blue, mixture in green

Assist to detect drug and explosive powder

Special features:

Network interface: Capable of connecting to LAN, and support multi-terminal check for baggage at same time

Safety ray: Ray is transmitted under automatic control, avoiding the error

One-key shutdown control: Just rotate the key to shut down the machine; it is safety, easy and convenient

Eagle eye: Capable of expediently observing the magnifying area

Self-diagnosis function: Give message automatically if malfunction for prompt maintenance

Color quality: 24-Bit real colors based on materials
