Acrylics Material Facial Recognization Access Control Temperature Testing System UT690

UNIQSCAN Faces Capacity Facial Recognization Temperature Testing System UT690

AI biometric technology that uses the infrared sensor to measure and record the body temperature in real time based on the facial feature information of the person. This device is based on a multi-task cascaded convolutional neural network face algorithm Technology to effectively extract, identify and compare human facial features, support face recognition by wearing a mask, and measure body temperature, which is widely used.

One of the main symptoms of a viral infection is an abnormal body temperature.

The normal body temperature ranges from 36.5 ° C to 37 °C, and if it exceeds 37.3 °C, it is a true pathological fever.

Specifications

• 5.0 inch capacitive touch screen 854 * 480
• Fast Temperature Detection: non-contact body surface temperature measurement within 1 second, which avoids cross infection
• Accuracy: ±0.3 ~ 0.5 ℃
• Valid Distance: 0.3-0.5 meter
• Voice Alarm for Abnormal Temperature Cases
• Ambient temperature: -20 ℃ ~ 65 ℃
• Temperature sensor measure range: -40 ℃ ~ 85 ℃
• Facial + Temperature verification to reject abnormal access

• Technology platform: LINUX intelligent operating system
• Dynamic face recognition verification, password verification, face + password verification, (customizable ID/IC card)
• Running memory : 4GBit DDR3, storage capacity 32GBit.
• Face recognition accuracy better than 99%
• Embedded & integrated design
• Collection, detection, comparison and living judgement on one device
• Support output 485 and Wiegand signals: can be seamlessly connected with various access controllers, support wg26, wg34
• Automatic adaptation to light environment
• Face storage: 3,000 faces, 1 million records
• Support extended 1: 1 witness identification, 1: n face recognition
• Face recognition speed : 0.2 seconds
• Flexible way to import face templates, support single, batch image file import and real-time capture of registered faces
• It can run offline in the disconnected mode without relying on computer control.
• Visible light + infrared light binocular live detection and recognition to prevent fraud on mobile phone photos and videos
• Support online photo import or photo registration, face registration directly on the touch screen, u disk import photo registration face
• Support wearing face mask to register face, wearing face mask to brush face recognition
• Multiple authentication modes: face, password, credit card (optional) and other modes
• Powerful access control functions and rich access control input and output interfaces
• Conventional temperature measurement mode: wear a mask to register, open the door when the temperature is normal when you brush your face, and do not open the door if the alarm is exceeded.
• The temperature measurement function can be turned off if epidemic ends, which can be used for dynamic face access control attendance
• Alarm temperature can be customized
• Voice prompt "normal body temperature" when body temperature is normal, voice abnormal "body temperature abnormality" when body temperature is abnormal
