L shaped array detector 24bit X Ray Baggage Scanner With 19 Inch Screen

China SHENZHEN UNISEC TECHNOLOGY CO.,LTD certification
China SHENZHEN UNISEC TECHNOLOGY CO.,LTD certification
Excellent! X RAY scanner be used on the airport, works very well and very stable !

—— Mr Anderson-USA

Good quality, good service! To cooperate with Uniqscan members is really happy thing!

—— Mr. Vijay-Saudi Arabia

It is my pleasure to have cooperation with UNIQSCAN,It is very stable used in the Hotal

—— Dr Mahammed-Bangeladesh

I can tell you are one of the best partners in China, because you are so professional in what you do, I can only praise your dedication and knowledge.

—— Mr stan -UK

I'm Online Chat Now

L shaped array detector 24bit X Ray Baggage Scanner With 19 Inch Screen

large.img.alt
small.img.alt

Large Image :  L shaped array detector 24bit X Ray Baggage Scanner With 19 Inch Screen

Product Details:
Place of Origin: China
Brand Name: Uniqscan
Certification: CE ISO
Model Number: SF5336
Payment & Shipping Terms:
Minimum Order Quantity: 1 UNIT
Price: negotiation
Packaging Details: Wooden box
Delivery Time: in one week
Payment Terms: T/T
Supply Ability: 100sets per month
Detailed Product Description
Product Name:: Airport Baggage Scanner Conveyor Speed:: 0.22m/s
Tunnel Size :: 560 (W) ×360 (H) Mm Storage Temperature:: -20oC To 60oC
Operating Temperature:: 0oC To 45oC Wire Resolution:: 40AWG
Steel Penetration:: 40mm Film Safety:: For ISO 1600
High Light:

baggage x ray machine

,

airport x ray machines



L-shaped array detector , 24bit X Ray Baggage Scanner With 19 Inch Screen



General Specifications:

Conveyor Speed: 0.22m/s
Conveyor Max Load: 150 kg
Tunnel Size : 560 (W) ×360 (H) mm
Wire Resolution: 40AWG
Steel Penetration: 40mm
Leakage radiation: <0.06µGy/h
Single inspection dosage: <1.01μGy



X-RAY GENERATOR:

  • Orientation: Upward
  • Tube Current: 0.4-1.25mA(adjustable)
  • Anode Voltage: 80-160KV(adjustable)
  • Angle: 80°
  • Generator cooling/working periods:
  • Sealed oil bath with forced air/100%

OPERATING ENVIRONMENT:

Storage Temperature: -20oC to 60oC
Operating Temperature: 0oC to 45oC
Relative Humidity: 20 to 95% non-condensing
System Power: 220 VAC (±10%) 50±3HZ
Power wastage: 1.0 KW (Max)
Noise: <55DB



X-RAY Sensor: L-shaped array detector, 24bit



Image Performance System:

  • Display: High-resolution 19 inch color LCD display
  • Color quality: 24-Bit real colors based on materials
  • Edge enhancement: Object contour edge is more distinct
  • Super image enhancement: Image detail is more distinct
  • High penetration display: Increase the contrast of bright area in image to make the area that is easy to penetrate appear more clearly
  • Low penetration display: Increase the contrast of dark area in image to make the area that is difficult to penetrate appear more clearly.
  • Magnifier: Partial magnifying function
  • Brightening/dimming: Increase/Decrease brightness of image
  • Image recurrence: Display the previous twenty images and process any one of them
  • Image restoration: Restore image to initial status
  • Image storage: Real-time store any image and process it in operation status



Multi-energy: High/low energy: Switch from high energy to low energy



Color material identification: Organic objects in orange, inorganic objects in blue, mixture in green

Assist to detect drug and explosive powder



Special features:

  • Network interface: Capable of connecting to LAN, and support multi-terminal check for baggage at same time,
  • Safety ray: Ray is transmitted under automatic control, avoiding the error,
  • One-key shutdown control: Just rotate the key to shut down the machine; it is safety, easy and convenient
  • Eagle eye: Capable of expediently observing the magnifying area
  • Self-diagnosis function: Give message automatically if malfunction for prompt maintenance

L shaped array detector 24bit X Ray Baggage Scanner With 19 Inch Screen 0
