18 Zones Door Frame Metal Detector 6 Digitals LCD Counter For Airport / Train Station

large.img.alt
small.img.alt

Large Image :  18 Zones Door Frame Metal Detector 6 Digitals LCD Counter For Airport / Train Station

Product Details:
Place of Origin: Guangdong(China mainland)
Brand Name: UNIQSCAN
Certification: CE,ISO
Model Number: UB600
Payment & Shipping Terms:
Minimum Order Quantity: 1 Piece
Price: USD450/piece
Packaging Details: Carton Box<p style="border: 0px; line-height: 15.6px; font-family: Arial, Helvetica; vertical-align: baseline; color: #333333;"><span style="color: #ff6600;"><strong><span style="font-size: 24px;">UB600 password protection with 18 zones adjusted sensitivit
Delivery Time: 7 days after the payment
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 500pieces/month
Detailed Product Description
Power Supply:: AC85V-264V Working Temperature:: -20℃--+50℃
Working Frequency:: 4KHZ-8KHZ Standard External Size:: 2230mm(H)X830mm(W)X730mm(D)
Standard Internal Size:: 2010mm(H)X700mm(W)X500mm(D) Package Size For Door Panels:: 2280*730*210mm *1ctn
Package Size For Control Unit:: 780*380*260m*1ctn Gross Weight:: 65KG
Backup Battery: 4-8 Hours Use Domain: Port, Airport, Train Station, Hospital, Museum, Government, Hotel Etc.
High Light:

metal detector security gate

,

dfmd metal detector

Door Frame Metal Detector with 18 Zones & 6 digitals LCD counter



1,Specification

6/12/18 Zone Walk Through Metal Detector UB600
Parameters



Power Supply AC85V-264V
Working temperature -20℃--+50℃
Working Frequency 4KHZ—8KHZ
Standard External size 2200mm(H)X800mm(W)X580mm(D)
Standard Internal size 2010mm(H)X700mm(W)X500mm(D)
Package size for door panels 2290*560*180mm *1ctn
Package size for control unit 760*380*260 mm*1ctn
Gross weight 65KG


Characteristic & Function

Ø  18 mutual over-lapping detecting zones, Simultaneous alarm from multi- zones;

Ø  Small LCD screen, English operating software, easy to operate.

Ø  Sensitivity adjustable: Each zone has 256 sensitivity level, 0-255 adjustable

Ø  Sound & LED alarm: Both Side LED indicator ,

easily show where the metal is.

Ø  Automatically count passengers and alarm times

Ø  Alarm strength indicator on control panel

Ø  Password protection, only the authorized person can operate.

Ø  Easy assembly: designed with only 2 pieces cables and 8 screws, simply-to-follow instruction.

Ø  Harmless to human body: is harmless with heart pacemaker, pregnant women, magnetic floppy, recording tapes, etc.

Ø  Using high density fireproof material

Ø  Program Self-diagnostic when power on,no need initial or periodic calibration

Ø  Modularization design,easy for maintenance and replacement.

Ø  Sensitivity Test piece: One yuan Coin, omnidirectional detection

Ø  4-8 hours backup battery (Option)


Use domain
Exhibition center, Electronic Factory, Bank, Prison, Government office,Hotel etc
