7 Inch Screen Multi Zone Metal Detector , 33 zones walk through metal detector

large.img.alt
small.img.alt

Large Image :  7 Inch Screen Multi Zone Metal Detector , 33 zones walk through metal detector

Product Details:
Place of Origin: China
Brand Name: uniqscan
Certification: CE , ISO
Model Number: UZ800
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiation
Packaging Details: packing : door panels: 2290*560*190mm *1ctn , control unit: 760*380*260m*1ctn
Delivery Time: 1500 pcs/month
Payment Terms: Western Union, T/T, L/C
Supply Ability: 3-7days after payment
Detailed Product Description
Product Name:: Walk Through Metal Detector Sensitivity :: 0-299 Sensitivity Level
Display Way:: 7 Inch Color LCD Screen Frequencies:: 100 Frequencies For Option
Detector Zone :: 33 Zones Warranty:: 2 Years
Operation Temperature:: -20℃--+50℃ Gross Weight:: 70 Kg
High Light:

pass through metal detector

,

metal detector security doors



7 Inch Screen Multi Zone Metal Detector , 33 zones walk through metal detector


Our Model :

  • UB500 with 6 zones
  • UB600 with 6/12/18 zones
  • UB700 with 6/8/16/24/33 zones
  • UM600 with 6/12/18 zones
  • UZ800 with 33/45 zones



Product Point :

1.........................33 detecting zones

2.........................Each zone has 300 sensitivity level

3.........................7 inch color LCD screen

4.........................100 frequencies for option

5.........................30 preset programs for security applications

6.........................4-8 hours backup battery for option



Date Sheet :

Detecting zone: 33 detecting zones
Display way: 7 inch color LCD screen
Sensitivity: Each zone has 300 sensitivity level
Power Supply: AC85V-264V / 47.5-60Hz
Working temperature: -20℃--+50℃
Working Frequency: 4KHZ—8KHZ
Gross weight: 70KG
Warranty: 2 years
Package size for door panels: 2260*650*260mm *1ctn
Package size for control unit: 780*390*250 mm*1ctn



Characteristic & Function:

  • 33 detecting zones, Simultaneous alarm from multi- zones;
  • Sensitivity adjustable: Each zone has 300 sensitivity level
  • 7 inch color LCD screen
  • Infrared remote control
  • Using high density fireproof material
  • 8 hours backup battery
  • Automatically count passengers and alarm times
  • IN / OUT counter: bi-directional counter
  • High sensitivity: Ferrous/ non-ferrous /Alloy can be detected
  • 30 preset programs for security applications
  • Anti-interference function, using advanced interactive transmitting and receiving to avoid interference.
  • 100 frequencies for option. To work with neighbouring gates at 40cm
  • Sound & LED alarm: Two Sides LED indicator easily show where the metal is.
  • Detecting speed: up to 100 passenger/ min.
  • Power save: Automatically power OFF if no passengers in 5 mins. Once pass through the gate, it will automatic working.
  • Password protection, only the authorized person can operate.
  • Easy assembly: designed with only 2 pieces cables and 8 screws,
  • Simply-to-follow instruction. Modularization design,easy for maintenance and replacement.
  • Harmless to human body: is harmless with heart pacemaker, pregnant women, magnetic floppy, recording tapes, etc.
  • Sensitivity Test piece: One yuan Coin, omnidirectional detection
  • Network support
  • Can be customized 45 zones



Application:

  • Airports
  • Correctional Facilities
  • Public Buildings
  • Private Buildings
  • Schools
  • Special Events
  • Loss Prevention
  • Nuclear Facilities
  • Transportation Terminals
  • Courthouses
  • Corporate Security
  • Historical Landmarks
