Public Area Portable Metal Detector Archway / Walk Through Security Scanners 24 Detecting Zones
The UB700 s modular design allows for a quick and simple assembly of its four sub-assemblies using only eight screws and three internal electrical connections.
24 Distinct Pinpoint Detection Zones
The ub700 offers exclusive multiple target pinpointing with 24 distinct zones for full target coverage on the left, center and right side of the body from head to toe.
Overhead Control Unit
LCD Display, alarm lights, LED bar graphs and control touchpads plus all wiring, connections and electronics are integrated into a single lockable overhead compartment which eliminates exposure of wires and external control box.
Multi-dimensional Coil Design
The UB700 exclusive multi-dimensional coil design provides unmatched detection of potentially lethal metal items such as guns, knives and other flat and rod-shaped weapons regardless of location and orientation.
Audible and Visual Alarms
Audible alarm and Visual Green LED lights signal when a target has been detected.
1. Superior target detection with unmatched discrimination of harmless items such as coins, jewelry, keys, cigarette packs, etc.
2. The ultimate in safety, throughput and reliability with preset programs to cover the most complete range of security applications including the new Enhanced Metal Detector (EMD) required for all airport installations.
3. Multi-dimensional coil design (8 distinct pinpoint zones) provides superior detection and location of guns, knives and other flat and rod-shaped weapons regardless of orientation.
4. Circuitry with advanced Digital Signal Processor (DSP) technology locates even small, hard-to-find, floor level weapons.
5. Individual zone boost adjustments allow for customization of detection characteristics and/or compensation for metallic environmental challenges.
6. Durable, IP65 weather-proof construction.
- Operating Temperatures
-4°F (-20°C) to + 158°F (70°C); Humidity: To 95% non-condensing
Fully automatic 100 to 240 VAC, 50 or 60 Hertz, 5 watts; no rewiring, switching or adjustments required. Power supply meets UL, CE,FCC standards.
- Weatherproofing / Foreign Object Protection Standards
All settings are secured with a key lock and two levels of access codes. Further security is accomplished with a cabinet lock which prevents unauthorized access to physical cables, connectors and electronics.
Attractive scratch and mar-resistant laminate. Detection Heads and Support: Heavy duty aluminum.
- Control Outputs
Solid state switches (low voltage AC or DC) for operating external alarms and control devices.
- Traffic Counter
Counter tracks the number of patrons that have passed through the detector, the number of alarms and calculates alarm percentage.
Dual channels and DSP circuitry allow several UB700 to operate simultaneously in close proximity to one another.
- Interference Suppression
Special Security King DSP built-in circuitry eliminates effects from x-ray monitors and other potential electrical interference sources.
Audible tone and volume adjustable. Bright LED visual alarm.
- Target Pinpointing Lights
24 distinct zones are displayed with 2 independent columns of LED's located on exit side of UB700.
- Pacing Lights
Limited 24 months, parts and labor
|Work environment||-20°C- +45°C|
|Standard||GB15210-2003<WALK THROUGH METAL DETECTOR>|
|Instruction||ONE (Including one Certificate of Quality & Guarantee Repair List)|
Slipping groove: Let the personal belongings which may be interference (such as keys, watches, cell, etc) slip through.
Remote Control: Control the gate within 10 meters, when paralleled the distance should be short.
Storage Battery: Maintain the gate working for about 4 hours after charged.
