0 To 255 Sensitivity Pass Through Metal Detector

large.img.alt
small.img.alt

Large Image :  0 To 255 Sensitivity Pass Through Metal Detector

Product Details:
Place of Origin: China
Brand Name: uniqscan
Certification: CE , ISO
Model Number: UB700
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiation
Packaging Details: packing : door panels: 2290*560*190mm *1ctn , control unit: 760*380*260m*1ctn
Delivery Time: 1500 pcs/month
Payment Terms: Western Union, T/T, L/C
Supply Ability: 3-7days after payment
Detailed Product Description
Product Name:: Walk Through Metal Detector Sensitivity :: 0 To 255 Sensitivity
Display Way:: 5.7 Inch LCD Screen Sound & LED Alarm:: Both Side LED Indicator
Detection Zone:: 6/18/24/33 Zones Working Frequency:: 4KHZ—8KHZ
Operation Temperature:: -20℃--+50℃ Backup Battery:: 4 Hours (Option)
High Light:

pass through metal detector

,

security walk through gate



0 to 255 sensitivity , large LCD screen Multi Zone Metal Detector for outdoor



Advantage:



Detector zone 6/18/24/33 zones
Sensitivity : 0 to 255 sensitivity
backup battery: approx 4 hours (Option)
package volume : 90 pcs for 20" container





Parameters:

  • Power Supply:AC85V-264V
  • Working temperature:-20℃--+50℃
  • Working Frequency :4KHZ—8KHZ
  • Standard External size: 2200mm(H)X800mm(W)X580mm(D)
  • Standard Internal size: 2010mm(H)X700mm(W)X500mm(D)
  • Package size for door panels: 2260*650*260mm *1ctn
  • Package size for control unit: 780*390*250 mm*1ctn
  • Gross weight: 70KG

Examining Standard:

  • Electrical Equipments standardized by EN60950.
  • Radiation standardized by EN50081-1.
  • Anti-inference standardized by EB50082.
  • Execute the standard of National Standard of Metal Detector

Characteristic & Function:

  • Six mutual over-lapping detecting zones, Simultaneous alarm from multi- zones;
  • Sensitivity adjustable: Each zone has 256 sensitivity level, 0-255 adjustable
  • 5.7 inch LCD screen
  • Infrared remote control
  • Sound & LED alarm: Both Side LED indicator ,easily show where the metal is.
  • Automatically count passengers and alarm times
  • Alarm strength indicator on control panel
  • Password protection, only the authorized person can operate.
  • Easy assembly: designed with only 2 pieces cables and 8 screws, simply-to-follow instruction.
  • Harmless to human body: is harmless with heart pacemaker, pregnant women, magnetic floppy, recording tapes, etc.
  • Using high density fireproof material
  • Program Self-diagnostic when power on, no need initial or periodic calibration
  • Modularization design, easy for maintenance and replacement.
  • Sensitivity Test piece: One yuan Coin, omnidirectional detection
  • 4-8 hours backup battery (Option)

Applications:

  • Airports
  • Correctional Facilities
  • Public Buildings
  • Private Buildings
  • Schools
  • Special Events
  • Loss Prevention
  • Nuclear Facilities
  • Transportation Terminals
  • Courthouses
  • Corporate Security
  • Historical Landmarks

0 To 255 Sensitivity Pass Through Metal Detector 0
